Description
| Model No.: | SX-112A2 |
| Physical Parameter | |
| Material | ABS+PC |
| Power Supply | DC 5V ±5% |
| Electric Current | 0.18A（standby）；0.25A（working）；0.32A（maximum） 【Average electric current】 |
| Power Consumption | 0.90W（standby）；1.25W（working）；1.60W（maximum） 【Average power consumption】 |
| Weight | 308.0g±5g（Without cable） |
| Size | L*W*H: 110.0 * 99.3 * 149.6（unit：mm） |
| Color | Black+orange |
| Performance Parameter | |
| Interface | USB |
| System Supported | Linux，Android，Windows XP、7、8、10，MAC |
| Language Supported | English-America；Belgian；Finnish；French；German；Italian；Swedish；English-United Kingdom；Danish；Norwegian；Spanish；Portuguese；Turkish-Q；Turkish-F；Japanese；Russian；Czech；Thai；Ukrainian；Portuguese-Brazil；Greek；Hungarian；Dutch；Polish；Romanian；Slovak； 【Virtual keyboard support】 |
| Sensor | Planar CMOS sensor 480 * 640 |
| Light Source | White LED |
| Professor | 32-bit ARM MCU + DSP |
| Motion Tolerance | 35cm/sec【10mil QR】 |
| Resolution | Code39 ≥5mil |
| Bit Error Rate | 1/5,000,000 |
| Reading Mode | Image |
| Trigger Mode | Auto-Sensing |
| Prompt Mode | Buzzer, Indicator Light（Green LED） |
| Scanning Angel | Roll 360°，Pitch ± 55°，Yew ± 55° |
| Invoicing function | Support |
| Print Contrast | ≥30% |
| Decoding Capability | 1D ■UPC-A ■JAN/EAN-8 ■JAN/EAN-13 ■Code 128 ■Code 39 ■Codabar ■Code 93 ■Interleaved 2 of 5 ■UPC-E ■UCC/EAN 128 ■GS1-128 ■ISBN-13 ■Industrial（Standard）2 of 5 ■Code 11 ■MSI Plessey ■Code32 ■GS1 Composite ■GS1 Databar ■Composite ■Matrix 2 of 5 |
| 2D ■PDF417 ■Micro QR Code ■QR Code ■Aztec code ■Data Matrix | |
| Scanning Depth | QR Code 12.50mil（7 bytes）：0cm – 11cm PDF417 9.17mil（7 bytes）：0cm -11cm Data Matrix 12.50mil（8 bytes）：0cm – 7cm Code 128 7.50mil（15 bytes）：1cm – 10cm EAN13（10mil）：3cm – 12cm |
| Environment Parameter | |
| IP Grade | IP52 |
| Operating Temp. | 0 to 50℃ / 32 to 122℉ |
| Storage Temp. | 0 to 50℃ / 32 to 122℉ |
| Operating Humidity | 20% to 85%（No Condensation） |
| Storage Humidity | 20% to 85%（No Condensation） |
| ESD Protection | 15KV air discharge |
| Shock Resistance | 1.2m free fall on concrete surface |
| Ambient Light | 0~100000LUX |
