Description
| Physical Parameter: | |
| Material: | ABS+PVC+PC |
| Power Supply: | DC 5V±5% |
| Operating Current | 50ma(Operating), 40ma(Stand By), 100ma(Max) |
| Weight: | 131±5g (With the cable) |
| Size: | L*W*H: 161*88*77(mm) |
| Color: | Black/Grayish white |
| Button Life: | ＞100000times |
| Performance Parameter: | |
| Interface | USB ,RS232 ,PS/2 |
| System Supported: | Linux，Android，Windows XP、7、8、10，MAC |
| Language Supported | English , German , France , Spainish , Italian , Japanse (Support International Keyboard Language) |
| Light Source | Visible Laser 650nm |
| Resolution | 4mil |
| Scanning Speed | 200scans / sec |
| Scanning Mode | Manual , Continuous scanning, Auto Sensing |
| Scanning Distance | 10-600mm |
| Prompt Mode | Buzzer, Indicator light(LED) |
| Decoding capability | UPC-A, UPC-E, EAN-13, EAN-8, ISBN/ISSN, Code39, Code Bar,Interleaved / ITF 25, Industrial 25, Code 128, Code 93, Code 11, MSI/PIESSEY, UCC/EAN128 |
| Scanning Angel | Roll35°,Pitch75°,Yaw75° |
| Depth Of Field | 2—9cm(0.1mm Width), 3—50cm(0.3mm Width) |
| Environment Parameter | |
| IP Grade | IP42 |
| Operating Temp. | -20 to 50℃ |
| Storage Temp. | -20 to 60℃ |
| Operating Humidity | 0 – 95% (No condensing) |
| Storage Humidity | 5 – 95% (No condensing) |
| ESD protection | 15kv |
| Shock Resistance | 1.5m free fall on concrete surface |
